Product Description

The RELAYSTAR-806 is universal and portable protection relay test set with three current outputs and four voltage outputs to test single and three phase protective relays.

The RELAYSTAR-806 comprises of three independent current output channels and four independent voltage output channels. This enables the unit to be used as a complete single-phase equipment (voltage, current, and phase angle between them) or, with channels synchronised, as a three phase current or four phase voltage generator from a single phase mains input.

The RELAYSTAR-806 also allows optional connection to a computer for either automatic testing of relays or control of the equipment using Windows compatible software.



Main Features
1) Embedded industrial PC with 8" LCD screen
2) Stand-alone operation, no PC required to operate
3) 3-phase current+ 4-phase voltage outputs
4) Perform multi-phase tests
5) Perform acceptance or troubleshooting tests in COMTRADE format
6) Dynamic GPS satellite synchronized end-to- end testing capability



Technical Data
Current Generator

Setting Range

3-Phase AC(L-N)

3x0…40A

1-Phase AC(LL-LN)

1x0…120A

DC(L-N)

3x…±10A

Power

3-Phase AC(L-N)

3x300VA At 40A

1-Phase AC(LL-LN)

1x1000VA At 120A

DC(L-N)

3x120VA At 10A

Accuracy

AC: ±1mA(≤0.2A), ≤0.1% (0.2~40A)

DC: ±5mA(0~0.5A), ≤0.2% (0.5~10A)

Resolution

1mA



Voltage Generator

Setting Range

4-Phase AC(L-N)

4x0…150V

1-Phase AC(L-L)

1x0…300V

DC(L-N)

3x…±160V

Power

4-Phase AC(L-N)

4x70VA At 150V

1-Phase AC(L-L)

1x140VA At 300V

DC(L-N)

3x80VA At 160V

Accuracy

AC: ±2mV(0.2~2V), ≤0.1% (2~150V)

DC: ±10mV (0~5V), ≤0.2% (5~160V)

Resolution

1mV



Auxiliary DC Supply

Voltage Range

110V/220V(Max.1.5A)

Power

Max.165VA/330VA



Binary Inputs

Number

8

Input Characteristics

Idle Contact Or Potential-Free Contact

Threshold Characteristics

"0":0~6V; "1":12V~250V

Max. Measuring Time

999999.999s

Time Accuracy

±1ms

Time Resolution

1ms



Binary Outputs

Number

4

Type

Idle Contact

Break Capacity

250VAC/0.5A, 250VDC/0.2A



General Generators

Frequency

Range: 0~1200Hz

Accuracy:<1mHz(0~65Hz),<10mHz(65~450Hz),<20mHz(450~1200Hz)

Resolution: 0.001Hz

Phase

Range: -360° ~+360°

Accuracy: 0.1°

Resolution: 0.01°

Harmonic

Superposition Order: 2~24 Times

Distortion: ≤0.5%



Power Supply

Nominal Input Voltage

Customized (AC 220V/230V/120V/127V±10%, 1-Phase)

Nominal Frequency

50/60 Hz

Rated Current

10A At 230V / 12A At 115V

Connection

Standard AC Socket (IEC 60320)



Environmental Conditions

Operation Temperature

0 ... +50 °C (+32 ... +122 °F)

Storage Temperature

-25 ... +70 °C (-13 ... +158 °F)

Humidity Range

Relative Humidity 5 ... 95 %, Non-Condensing

Vibration

IEC 60068-2-6(20m/S2 At 10 ... 150 Hz)



Miscellaneous

Weight

18kg(39.68 Lb)

Dimensions (W X H X D, Without Handle)

405×300×164mm(15.94x11.81x6.46 In)

Connection Port

2 USB2.0 Ports, 1 Ethernet Port



Safety Standards, Electromagnetic Compatibility

EMC

The Product Adheres To The Electromagnetic Compatibility (EMC) Directive 2004/108/EC(CE Conform)

IEC 61326-1; IEC 61000-6-4; IEC 61000-3-2/3

Safety

The Product Adheres To The Low Voltage Directive 2006/95/EC(CE Conform).

IEC 61010-1



3-phase Protection Relay Test Set RELAYSTAR-806 passed the Type Test in China KETOP laboratory accredited under ISO/IEC 17025.
