Product Description

Economical 3-phase Relay Tester

Model: RELAYSTAR-702



Descriptions

The RELAYSTAR-702 is classic 3-phase protection relay tester, which was launched to the market since 1999. It can be used for testing electro-mechanical, solid-state and microprocessor-based protection relays.

The PC software of RELAYSTAR-702 is designed based on Windows system, easy and convenient for operation and upgrade.

The RELAYSTAR-702 is the most economical choice for relay testing engineers.



Main Features

1) 3-phase current(3×40A) + 4-phase voltage(4×120V) output

2) Both local test and PC remote test available

3) Embedded system with 320×240 LCD screen

4) High performance linear power amplifier

5) 8 binary inputs + 4 binary outputs

6) Independent Aux. DC

7) Powerful software testing function



Technical Data

Current Generator

Setting Range

3-Phase AC(L-N)

3x0…40A

1-Phase AC(LL-LN)

1x0…120A



DC(L-N)

3x…±10A




3-Phase AC(L-N)

3x420VA At 40A

Power

1-Phase AC(LL-LN)

1x900VA At 120A



DC(L-N)

3x120VA At 10A

Accuracy

AC: ≤0.2%



DC: ≤0.5%





Voltage Generator

Setting Range

4-Phase AC(L-N)

4x0…120V

1-Phase AC(L-L)

1x0…240V



DC(L-N)

3x…±160V



Power

4-Phase AC(L-N)

4x80VA At 120V

1-Phase AC(L-L)

1x100VA At 240V



DC(L-N)

3x70VA At 160V



Accuracy

AC: ≤0.2%



DC: ≤0.5%





Auxiliary DC Supply

Voltage Range

110V/220V(Max.1.5A)

Power

Max.165VA/330VA



Digital Inputs

Number

8

Input Characteristics

Idle Contact Or Potential-Free Contact

Threshold Characteristics

"0":0~6V; "1":11V~250V

Max. Measuring Time

0.1ms~9999s

Time Accuracy

0.1ms



Digital Outputs

Number

4

Type

Idle Contact

Break Capacity

220VAC/0.5A, 220VDC/0.2A



General Generators

Frequency

Range: 0~1000Hz(PC Mode), 20~300Hz(Local Mode)

Accuracy:<10mHz(0~450Hz),<20mHz(450~1000Hz)



Resolution: 0.01Hz



Phase

Range: 0~360°

Accuracy: 0.2°



Resolution: 0.1°



Harmonic

Superposition Orders: 1~20(PC Mode), 1~6(Local Mode),

Distortion: ≤0.5%





Power Supply

Nominal Input Voltage

Customized (AC 220V/230V/120V±10%, 1-Phase)

Nominal Frequency

50/60 Hz

Rated Current

10A At 230V / 12A At 115V

Connection

Standard AC Socket (IEC 60320)



Environmental Conditions

Operation Temperature

0 ... +50 °C (+32 ... +122 °F)

Storage Temperature

-25   ... +70 °C (-13 ... +158 °F)

Humidity Range

Relative Humidity 5 ... 95 %, Non-Condensing

Vibration

IEC 60068-2-6(20m/S2 At 10 ... 150 Hz)



Miscellaneous

Weight

22kg(48.50 Lb)

Dimensions (W X H X D, Without Handle)

400×300×180mm(15.75x11.81x7.09 In)

Connection Port

For PC Connection



RELAYSTAR-702 is the most cost-effective protection relay tester all over the world, and has reliable performance and low maintenance costs typical advantage. The cumulative sales over 5,000 units from 1999 to now.
